copy of Driver A4988 Shield CNC Module 3D Printing

Reference 21a.24

Driver A4988 Shield CNC Module 3D Printing

zł73.16

Quantity

Last items in stock

Polityka bezpieczeństwa (edytuj za pomocą modułu „Bezpieczeństwo klienta”)

Zasady dostawy (edytuj za pomocą modułu „Bezpieczeństwo klienta”)

Zasady zwrotu (edytuj za pomocą modułu „Bezpieczeństwo klienta”)

Description
Product Details

Description

Przedmiotem aukcji jest 1 szt Sterownika A4988 Shield CNC Druk 3D

Specyfikacja (and):

Feature

1.Uses removable A4988 or DRV8825 compatible stepper drivers.

2.The extension board can be used for carving machine,
3 d printer driver expansion board
3.GRBL 0.8 compatible. (Open source firmware that runs on an
for arduino UNO that turns G-code commands into stepper signals)
4.PWM Spindle and direction pins,4-Axis support
(X, Y, Z , A-Can duplicate X,Y,Z or do a full 4th axis with custom firmware using pins D12 and D13)
5.Compact design. Stepper Motors can be connected with 4 pin molex connectors or soldered in place.

It is a total of four slots, can drive four A4988 stepper motor. Each road stepper motors only need two IO ports. In other words, six IO ports can be well managed three stepper motors. Very convenient to use.

UNO for Arduino module IO port correspondence introduction.

UNO for Arduino---------------------- expansion board

8 ------------------------ EN ( stepper motor driver enable , active low )

7 ----------------------- Z.DIR (Z -axis direction control )

6 ----------------------- Y.DIR (Y -axis direction control )

5 ----------------------- X.DIR (X -axis direction control )

4 ---------------------- Z.STEP (Z -axis stepper control )

3 ---------------------- Y.STEP (Y -axis stepper control )

2 ---------------------- X.STEP (X -axis stepper control )

/ / The following is a simple stepper motor control procedures,

# define EN 8 / / stepper motor enable , active low

# define X_DIR 5 / / X -axis stepper motor direction control

# define Y_DIR 6 / / y -axis stepper motor direction control

# define Z_DIR 7 / / z axis stepper motor direction control

# define X_STP 2 / / x -axis stepper control

# define Y_STP 3 / / y -axis stepper control

# define Z_STP 4 / / z -axis stepper control

/ / Function : step . function: to control the direction of the stepper motor , the number of steps .

/ / Parameters : dir direction control , dirPin corresponding stepper motor DIR pin , stepperPin corresponding stepper motor " step " pin , Step number of step of no return value.

void step (boolean dir, byte dirPin, byte stepperPin, int steps)

digitalWrite (dirPin, dir);

delay (50);

for (int i = 0; i <steps; i + +)

digitalWrite (stepperPin, HIGH);

delayMicroseconds (800);

digitalWrite (stepperPin, LOW);

delayMicroseconds (800);

Product Details

Reference 21a.24

In stock 3 Items
